Hydraulic Shearing Machine-E21S

Review the equipment and configuration below. Send your material, thickness, working dimensions and application to request a quotation for this machine.

Request a quotation for this machineDiscuss on WhatsApp
Shearing machine front
Shearing machine front
Shearing machine front
Shearing machine front
Shearing machine side
Shearing machine side
Behind the shearing machine
Behind the shearing machine
Behind the shearing machine
Behind the shearing machine
Shearing machine side
Shearing machine side
Shearing machine side
Shearing machine side
E21S system
E21S system
Siemens motor
Siemens motor
Standard Equipment
REQUEST INFORMATION
  • ESTUN E21S Controller
  • Electrics : Germany Schneider Electric
  • Main Motor:Siemens Motor-Germany
  • Frequency Converter:JRACDRIVE
  • Foot Switch:KACON- South Korea
  • Hydraulic System:Bosch Rexroth-Germany
  • Oil Pump :Sunny-USA
  • Sealing Ring :PARKER-America
  • High effciency motor - class IE3
  • Tube Connector :EMB-Germany
  • Backgauge:Ball Screw China
    • Introduction to Configuration

    QC12K NC hydraulic swing beam shearing machine with E21S has an all-steel welded structure and comprehensive treatment (vibration ageing, heat treatment) to remove internal stresses, resulting in excellent rigidity and stability. Precision sliding guides are used to eliminate guide gaps, resulting in high shearing quality. The E21S system is easy to operate.

    Technical Parameter


    ModelCutting ThicknessMax. Cutting LengthLength of Cutter Blade(A)Cutting AngleNumber of strokes(Hits/min)Backgauge Range of X AxisHeight of working table above the groundPowerL*W*H(mm)Weig

    ModelCutting ThicknessMax. Cutting LengthCutting AngleCutting Angle

    Number of

    strokes(Hits/min)

    		Backgauge Range of X AxisHeight of working table above the groundPowerL*W*H(mm)Weight
    QC11Y/K-4*25004mm2500mm2600mm1°308-14550mm800mm5.5KW1850*1650*18504.1Ton
    QC11Y/K-4*32004mm3200mm3300mm1°308-14550mm800mm5.5KW2850*1650*18503.8Ton
    QC11Y/K-4*40004mm4000mm4100mm1°308-14550mm800mm5.5KW2850*1750*18505Ton
    QC11Y/K-4*60004mm6000mm6100mm1°308-14550mm800mm7.5KW3550*1750*18505.5Ton
    QC11Y/K-6*25006mm2500mm2600mm1°308-14550mm800mm7.5KW2850*1750*18805.85Ton
    QC11Y/K-6*32006mm3200mm3300mm1°308-14550mm800mm7.5KW3650*1850*18806.5Ton
    QC11Y/K-6*40006mm4000mm4100mm1°3010550mm800mm7.5KW4650*1850*18807.8Ton
    QC11Y/K-6*60006mm6000mm6100mm1°3010550mm800mm11KW6450*1850*188018Ton
    QC11Y/K-8*25008mm2500mm2600mm1°3014550mm900mm7.5KW2850*1750*19507.2Ton
    QC11Y/K-8*32008mm3200mm3300mm1°3014550mm900mm7.5KW3650*1750*19508Ton
    QC11Y/K-8*40008mm4000mm4100mm1°3014550mm900mm11KW4650*1750*19509.5Ton
    QC11Y/K-8*60008mm6000mm6100mm1°3014550mm900mm15KW6450*1750*195018.5Ton
    QC11Y/K-12*250012mm2500mm2600mm1°3014550mm1000mm11KW2850*1750*205010.3Ton
    QC11Y/K-12*320012mm3200mm3300mm1°3014550mm1000mm11KW3650*1750*205011.2Ton
    QC11Y/K-12*400012mm4000mm4100mm1°3014550mm1000mm11KW4650*1750*205013Ton
    QC11Y/K-12*600012mm6000mm6100mm1°3014550mm1000mm15KW6450*1750*205025.5Ton
    QC11Y/K-16*250016mm2500mm2600mm1°3014550mm1000mm11KW2850*1750*215012Ton
    QC11Y/K-16*320016mm3200mm3300mm1°3014550mm1000mm15KW3650*1750*215012.5Ton
    QC11Y/K-16*400016mm4000mm4100mm1°3014550mm1000mm22KW6450*1750*215028.5Ton


                                                    Optional CNC system


    ESTUN E200PS

    ★Backgauge control

    ★BUS mode control servo system

    ★Stroke length limitation

    ★Double programmable digital output

    ★Program memory of up to 40 programs up to 25 steps per program

    ★One side positioning

    ★ Retract function

    ★Mm/Inch

    ★Chinese/English


    Delem DAC-310T

    ★Panel based housing

    ★Bright LCD screen

    ★Back gauge control

    ★Retract function

    ★Cutting angle or gap control

    ★Stroke length limitation

    ★Manual movement of axes

    ★Stock count




    Delem DAC-360T

    ★Panel based housing

    ★Bright LCD screen

    ★Back/front gauge control

    ★Retract function

    ★Cutting angle and gap control

    ★Stroke length limitation

    ★Manual movement of all axes

    ★Force control

    ★Sheet thickness measurement

    ★Return to Sender function

    ★Second and third servo axis(DAC-362T)

    ★Sheet support


    What to include in your inquiry

    Include your destination country, electrical supply and preferred machine options so we can discuss the installation and configuration requirements.
